E-glass Assembled Roving for Pultrusion
E glass Assembled Roving for Pultrusion is coated with silane and compatible with Polyester, Vinylester and Epoxy etc. It’s also compatible with many kinds of resins. It is widely used in the FRP extrusion molding and many kinds of FRP materials, such as tabernacles, gratings, poles, cable slot and so on.
|
Type of glass
|
E
|
|
Filament diameter (um)
|
13-24
|
|
Linear density (Tex)
|
1200, 2400, 4800, 9600
|
Product Characteristics:
Good mechanical properties
Complete & fast wet out in resins
No fuzz, even linear density
Uniform tension, good gathering
Technical Parameters:
|
Linear density
|
Filament diameter
|
Moisture content
|
LOI
|
|
±5%
|
±1um
|
≤0.10
|
0.55±0.15
|
Packaging:
The product can be packed on pallet in both small & big size pallet.
|
Bobbin height (mm)
|
260
|
|
Bobbin inside diameter (mm)
|
160
|
|
Bobbin outside diameter (mm)
|
270
|
|
Bobbin weight (kg )
|
15-21
|
|
Number of layers
|
3
|
4
|
|
Number of rolls per layer
|
16
|
|
Number of rolls per pallet
|
48
|
64
|
|
Net weight per pallet (kg)
|
720-1008
|
960-1344
|
|
Pallet length (mm)
|
1140
|
1140
|
|
Pallet width (mm)
|
1140
|
1140
|
|
Pallet height (mm)
|
955
|
1220
|
Storage:
Fiberglass roving should be stored in its original packing in a dry and cool place. Best conditions are at temperatures from 15 to 35℃ and humidity between 35 to 65%. To ensure safety and avoid damage to the product, the pallets should not be stacked more than three layers high, when the pallets are stacked in 2 or 3 layer, care should be taken to correctly and smoothly move the top pallet.
Application:
Shipment:
